Designed for Vibroseis, dynamite, and impulsive autonomous operation
|

|
Supports "stakeless" & "pointless" crew operation, node deployment, and data acquisition
|

|
"Scout Mode" for surveying, point staking, and line preparation (e.g. "bulldozer" mode)
|

|
Supports land and marine streamer operation
|

|
Includes layer support for keep-out areas, surface hazards, and low force zones
|

|
Android and Windows versions available
|
|

|
|
VibLink IP
Communications Via Internet

|
Uses Cellular Modems and Internet Servers
|

|
World-Wide Communications
|

|
Standard F3 Messaging
|

|
Optional internal coprocessor board, plus Wi-Fi networking transceiver
|
|

|
|
VibLink TDMA
Unit-to-Unit Communications

|
Uses VibLink Modules and VHF Radio
|

|
All In-Field Communications
|

|
Small, fast, 34-byte packets with status and commands
|

|
Optional internal coprocessor board, plus cellular data modem
|
|
VDisplay
Real-Time or Historical QC

|
Displays and stores VSS and PSS data
|

|
Displays data as graphs or tables
|

|
Identifies and displays anomalous sweeps
|

|
Displays and analyzes baseplate, reaction mass signals as wireline test
|
|
Featured for 2023...Seismographs
|
DAQlink 4
24 Channel, High-Speed Seismograph

|
12 or 24 Channel general purpose seismographs
|

|
Alternate case design for stacking DAQlinks vertically, for maximizing channels and minimizing space
|

|
Alternate version with high speed in-built networking, for creating seismographs with higher channel counts
|

|
Up to 32,000 SPS for shot records
|

|
Optimized for Land and Marine streamer acquisition, and for V30 and other near-surface projects
|
|

|
|
Sigma 3+ and 4+
3 or 4 Channels, Nodal Seismograph

|
Low noise 3 channel configuration
|

|
High speed 4 channel configuration
|

|
Optional equipment:
|
|
Internal battery
|
|
Internal Linux-based coprocessor
|
|
- Internal or external sensors
|
|
- Internal or external GPS module
|
|
- External microphone
|
|
- External Wi-Fi module
|
|
- External solar battery augmentation
|

|
Optimized for long-term or short-term monitoring projects
|
|

|
|
Unode2 for Sercel
Reuse 408/428 FDU/DSU Equipment

|
Each U·Node2 records 1-120 channels, can use multiple nodes for larger projects
|

|
Adds GPS, Wi-Fi, and autonomous features to system
|

|
Compatible with SSC Universal Encoder 3, Force 3, Boom Box 3 and SourceLink source control equipment
|

|
Replace or augment Sercel 408 or 428 systems
|
|

|
|
DX-6
6 Channel, Netwoked Seismograph

|
Real-Time data returned via the internal network
|

|
DX-6 nodes can be used either autonomously, individually with Wi-Fi, or networked together with cables
|

|
Nodal timing established via either GPS or NTP, can be used underground, or where GPS is not available
|

|
System can be triggered from any node, for ease of use and faster production
|

|
Optimized for real-time projects requiring hundreds of channels
|
|

|
|
Featured for 2023...Projects
|
MASW Acquisition
For Rapid MASW Data Acquisition

|
Build 6, 12 or 24 channel streamers using tough straps and solid aluminum sleds
|
|

|
Sled spacing customizable with each order
|
|

|
Sleds have outriggers for additional stability while towing
|
|

|
Connect streamer to towed source or directly to vehicle
|
|

|
Record streamer with DX-6 or DAQlink seismographs
|
|
|
UHRMS
Ultra-High Resolution Marine Seismic

|
Customized for fast acquisition of high-resolution data
|

|
Up to 16,000 SPS
|

|
Down to 100 milliseconds between shots
|

|
Up to 96 channels per streamer
|

|
Can acquired overlapping shot records: - Record Length > Shot Interval
|

|
Ideal for shallow marine hazard surveys
|
|

|

|
PPV Monitoring
PPV Monitoring with Seismic in Mind

|
Utilizes 3 or 4 channel Sigma 4+ digitizers
|

|
Available with VibLink TDMA or IP Communications
|

|
System options include Wi-Fi and external microphone
|

|
System is aware of source equipment locations
|

|
System alerts source operator of PPV violations
|

|
System is fully automatic
|

|
PPV Monitor can abort sweeps and prevent damage
|
|

|
|
V30 Analysis
Surface Waves plus Refraction

|
24 channel DAQlink 4 can acquire both surface wave and refraction datasets for V30 and near surface projects
|

|
Use SASW, MASW, ReMi and SPAC/ESPAC techniques
|

|
Switches from 10.Hz to 4.5 Hz (or 2 Hz) geophone elements for recording lower frequencies
|

|
Use the same equipment to acquire refraction datasets
|

|
Surface waves determine shear wave velocities for site classification, and refraction data helps determine structure, all for a complete answer
|
|

|
|
|
|
|
|
|
|
